BOTTLING DETAILS


Our bottling line includes the following features:

  • Bertolaso Unibloc Syncronia – Fully loaded 100bpm line with “no-oxygen” filling technology with Epica filler bowl, Delta Corker with vacuum system to eliminate cork dust, Sigma Screwcap machine with Stelvin Lux capabilities.

  • Domino 120i - Laser-etch capabilities for each bottle to apply serial codes, thereby supporting recalls and ensuring counterfeit protection.

  • Robino & Galandrio uses patented technology for capsule application with new generation pneumatic spinning heads

  • Cavagnino & Gatti labeler – provides perfect label placement with optical seam spotting technology

  • Weber 5300 Twin-Tamp Printer Applicator applies customized two-label, adjacent-panel applications in line to the case.

  • Logics & Controls system management provides a complete QA system that finds issues, which results in saved product and revenue. Features include:

    • Logilevel Plus – check fill height and reject low fills

    • Logipush – gentle push ejector for incorrect bottles

    • Logicork/Logicap – checks presence of cork or capsule

    • Logiclosure - checks integrity of screwcap post application

    • Logilook – checks the correct label is applied by “reading” the label

BOTTLING LINE REQUIREMENTS

Our bottling line has specific requirements and parameters for bottling based on clients’ needs. We also have custom-built sets of change parts that enable us to configure the line for various bottles, labels and closures. Bottling line requirements include:

Bottles sizes for still wines

Claret

Height: 302 mm max
Base diameter: 75mm max
Tapered diameter: 84mm max

Burgundy

Height: 296mm max
Diameter: 81mm/88mm

Hock

Height: 331mm max
Diameter: 76mm

We can run real or artificial cork closures

Max Length: 54m
Max Width: 24.5mm

We can accommodate multiple options for capsules, including Polylaminate, Tin and ATP.

ATP sizes are 60mm length max and 30mm diameter max

We can accommodate standard size, 30x60 Stelvin screwcaps.

Label specifications include:

  • Position 3 – label off the right

  • Separate front and back rolls required

  • PET or Kraft backing

  • MAX Label Height: 150mm/Min label length: 2mm

  • Core Diameter: Min 60mm/ Max 80mm

  • Max roll diameter: 350mm
